BASIC FEATURES

Function: Cooling
Capacity: 18,000 BTU/hr
Rated Voltage: AC 230V ~ 50Hz
DC Voltage (Hybrid): 48V to 400V
DC Voltage (Off-Grid): 120V to 400V*
*For Off-Grid operation, the DC power source must deliver the full power required to operate the AC.

Rated Current: 5.3A
Rated Capacity: 5275W
Rated Input Power: 1205W
EER: 4.38
Cooling & Operating Range: 20°C to 55°C

HEATING & COOLING FEATURES

Compressor Type: Rotary (Inverter)
Refrigerant Type: R-32
Refrigerant Amount: 0.62kg
Indoor Heat Exchanger Fin Type: Louvered Fin
Outdoor Heat Exchanger Tube Type: Wave Fin
Indoor Heat Exchanger Tube Type: Copper Tube
Maximum Pipe Length: 10m

OPERATIONS

Turbo Mode: Yes
Auto Operation: Yes
Dry Mode: Yes (Cooling Mode Only)
Fan Mode: Yes
Speed Setting: Yes (Auto, High, Medium, Low)
Auto Restart: Yes
Comfort Cooling: Yes
Timer: Yes
Sleep Mode: Yes

REMOTE & AIR DEFLECTION

Remote Display Type: LCD
Operation / Control: Via IR (Infrared Ray)
Child Lock Function: Yes
Temperature Unit Change: Yes
Auto Up-Down Swing: Yes
Auto Left-Right Swing: Yes

DIMENSIONS & WEIGHTS

Indoor Unit Dimensions (L × W × H): 942 × 321 × 238mm
Indoor Unit Packing Dimensions: 1025 × 400 × 300mm

Outdoor Unit Dimensions (L × W × H): 942 × 371 × 701mm
Outdoor Unit Packing Dimensions: 1015 × 440 × 775mm

Net Weight (Indoor): 13 ± 0.5kg
Gross Weight (Indoor): 15 ± 0.5kg
Net Weight (Outdoor): 37.8 ± 1kg
Gross Weight (Outdoor): 42.4 ± 1kg

GUARANTEE / WARRANTY INFORMATION

Product Replacement Guarantee: 1 Year
Note: Product replacement applies in cases of manufacturing faults in the compressor.

FOR RESIDENTIAL USAGE

Compressor Guarantee: 12 Years
Inverter PCB Warranty: 5 Years
Condenser Warranty: 3 Years
Spare Parts Support: 3 Years
After-Sales Service: 2 Years (Free)

FOR COMMERCIAL USAGE

Compressor Guarantee: 5 Years
Inverter PCB Warranty: 2 Years
Condenser Warranty: 2 Years
Spare Parts Support: 2 Years
After-Sales Service: 1 Year (Free)

TERMS & CONDITIONS

1. Warranty Exclusions

This warranty does not cover the following cases:

i) If the product is misused, neglected, or rented on a commercial basis. The warranty will also be invalid if the product is repaired, replaced, or modified by unauthorized service personnel.

ii) If the product serial number or barcode is removed, altered, or duplicated.

iii) Product defects caused by incorrect or negligent storage or use of the product.

iv) Failure to start due to voltage conditions, blown fuses, or other damage caused by inadequate or interrupted electrical service.

v) Product defects caused by exposure to extreme conditions, such as thunder, lightning, water ingress, fire, or obstruction of indoor and outdoor airflow.

vi) Damage or failure of the product caused by rats, cockroaches, insects, or other pests.

vii) If the unit is installed in a hazardous environment involving chemical fumes or corrosive substances such as acid solution, sulfur solution, hydrogen peroxide, sodium sulfate salt, hydrogen sulfide, chlorides, bleaching powder, ammonia, chlorine, IPA, thinner, etc.

viii) If the unit is installed in a kitchen or oily environment, or if any heat element or heat source is located very close to the indoor or outdoor unit.

2. Warranty Void Conditions for Inverter PCB in Residential Air Conditioners

a) Improper Installation: Warranty is void if the unit is installed by unauthorized personnel, using non-standard components, or without following the manufacturer's installation guidelines.

b) Unauthorized Repairs / Modifications: Any repairs, modifications, or use of non-authenticated parts without prior approval will nullify the warranty coverage.

c) Physical Damage: Damage caused by external impact, mishandling, moisture exposure, or burnt components due to short circuits is not covered.

d) Electrical Issues: Damage resulting from lightning, improper power supply, voltage fluctuations, or overloading will void the warranty.

e) Environmental Conditions: Operating the unit outside the recommended temperature or humidity range, exposure to water, or corrosion caused by pollutants will invalidate the warranty.

f) Neglect / Misuse: Lack of regular maintenance, improper use, or continued operation after detecting faults will not be covered.

g) Tampering: Altering or removing serial numbers, warranty labels, or other identifying markers will void the warranty.

h) Force Majeure: Natural disasters, accidents, or other unforeseen external events are not covered.

i) Improper Accessories: The use of uncertified external devices, wiring, or connectors will void the warranty.

j) Documentation Issues: Failure to provide proof of purchase, digital warranty registration, or service records may result in denial of warranty claims.

3. Repair and Replacement Policy

During the warranty period, products or parts will not be replaced if they are repairable. However, if repair is not possible, replacement will be provided in accordance with the applicable warranty policy. These conditions are intended to ensure transparency and set realistic expectations for customers.

4. Manufacturing Defects

This warranty covers only manufacturing defects, subject to verification by authorized company personnel.

5. After-Sales Service

After-sales service will be applicable only at company-authorized service points.

6. Warranty Policy Changes

The authority reserves the right to change, extend, correct, stop, or cancel the warranty period without prior notice.

7. Inverter PCB & After-Sales Service Warranty Update

Effective from August 1, 2025, all inverter air conditioners will come with a 5-year inverter PCB warranty and a 2-year after-sales service warranty.

For units purchased before August 1, 2025, a 3-year inverter PCB warranty and a 1-year after-sales service warranty will apply.

However, from April 1, 2025 to July 31, 2025, the 5-year inverter PCB warranty will apply only to the INVERNA, ACC, and MARLINE series.

8. Free Cleaning Service

A maximum of two free cleaning services will be provided during the 2-year after-sales service warranty period upon request.
