Walton 5 Ton Cassette Air Conditioner WCN-HEXACOMB-60Z
WCN-HEXACOMB-60Z
Air Conditioner Type: Cassette Air Conditioner
Function: Cooling
Cooling Capacity: 60,000 BTU/Hr
Cooling Capacity: 17,584 Watts
Capacity: 5 Ton
Compressor: Scroll (Fixed Speed)
Refrigerant: R-410a
WCN-HEXACOMB-60Z
Basic Features
Function: Cooling
BTU/hr: 60,000
Rated Voltage: 380V–420V ~ 50Hz
Rated Input Power: 5,800 W
Rated Current: 9 A
Cooling Capacity: 17,584 W
EER: 3.03
Cooling Features
Compressor Type: Scroll (Fixed Speed)
Refrigerant Type: R-410a
Refrigerant Amount: 3.15 kg
Operating Range (Ambient Temperature): 21°C to 43°C (Standard), 55°C (Maximum)
Heat Exchanger Type: Copper Tube (Evaporator), Copper Tube (Condenser)
Heat Exchanger Fin Type: Louvered Fin (Evaporator), Louvered Fin (Condenser)
Connecting Pipe Size: 15.88 × 0.8 mm (Vapor Line), 9.52 × 0.7 mm (Liquid Line)
Operations
Turbo Mode (Faster Cooling): No
Eco Mode: No
Display: 7 Segment LED
Auto Operation: Yes
Dry Mode: Yes
Fan Mode: Yes
Speed Setting: Yes (Auto, High, Medium, Low)
Auto Restart: Yes
Comfort Cooling: Yes
Timer: Yes
Sleep: Yes (30m)
Remote & Air Deflection
Display Type: LCD
Display Back Light: Yes
Operation/Control: Via IR (Infrared Ray)
Child Lock: Yes
Temperature Range: 16°C to 31°C
Temperature Unit Change: Yes (Degree Celsius to Fahrenheit)
Auto Up-Down Swing: Yes
Auto Left-Right Swing: No
Dimensions & Weights
Indoor Unit Dimensions: 840 × 840 × 310 mm (L × W × H)
Indoor Unit Packaging Dimensions: 890 × 890 × 345 mm
Front Panel Dimensions: 950 × 950 × 45 mm (L × W × H)
Front Panel Packaging Dimensions: 1025 × 1025 × 110 mm
Outdoor Unit Dimensions: 917 × 330 × 1260 mm (L × W × H)
Outdoor Unit Packaging Dimensions: 1030 × 475 × 1290 mm
Net Weight (Indoor): 37 ± 1 kg
Gross Weight (Indoor): 42 ± 1 kg
Net Weight (Outdoor): 103 ± 1 kg
Gross Weight (Outdoor): 125 ± 1 kg
Net Weight (Indoor Front Panel): 5.30 ± 0.25 kg
Gross Weight (Indoor Front Panel): 9.10 ± 0.25 kg
Guarantee & Warranty Information
Product Replacement Guarantee: 1 Year
Applicable in case of manufacturing faults in the heat exchanger and compressor.
For Commercial Usage
Compressor Guarantee: 5 Years
Spare Parts Support: 2 Years
After Sales Service: 1 Year (Free)
Terms & Conditions
This warranty does not cover the following cases:
If the product is misused, neglected, or rented on a commercial basis. The warranty will also be invalid if repaired, replaced, or modified by unauthorized service personnel.
If the product serial number or barcode is removed, altered, or duplicated.
Product defects caused by incorrect or negligent storage or use of the product.
Failure to start due to voltage conditions, blown fuses, or other damage caused by inadequacy or interruption of electrical service.
Product defects caused by exposure to extreme conditions such as thunder, lightning, water ingress, fire, or obstruction of indoor and outdoor airflow.
Damage or failure caused by rats, cockroaches, insects, or similar pests.
If the unit is installed in a hazardous environment involving chemical fumes or corrosive substances such as acid solution, sulfur solution, hydrogen peroxide, sodium sulfate salt, hydrogen sulfide, chlorides, bleaching powder, ammonia, chlorine, IPA, thinner, etc.
If the unit is installed in a kitchen or oily environment, or if any heat-producing element/source is located very close to the indoor or outdoor unit.
Warranty Notes
This warranty covers only manufacturing defects, subject to verification by authorized company personnel.
After-sales service is applicable only at company-authorized service points.
The authority reserves the right to change, extend, correct, stop, or cancel the warranty period without prior notice.
